Wiremold V20GB609 Ivory Raceway Base and Cover 72.5 in

Product Description

The WIREMOLD V20GB609 is an ivory-finished raceway base and cover section designed for surface-mounted wire management in commercial and residential electrical installations. At 72.5 inches in length, this single-piece raceway section provides a clean, paintable channel for routing low-voltage and line-voltage conductors along walls and ceilings without the need for in-wall rough-in. Electricians and low-voltage installers use this product to organize and protect exposed wiring runs in finished spaces where cutting into walls is not practical or permitted. The unit weighs 3.7 pounds and measures 3 inches by 1.5 inches in cross-section.

This raceway section is suited for use in office environments, classrooms, healthcare facilities, and residential retrofit projects where surface wiring must meet code and remain accessible for future changes. It is commonly installed along baseboards or at chair-rail height to conceal data, power, audio, or communication cables. The ivory finish blends with standard wall colors and accepts paint for further customization to match the surrounding decor.

Key Features

• 72.5-inch length provides extended single-run coverage with fewer splice points
• Ivory finish is paint-ready for seamless integration into finished interior spaces
• Base and cover design allows easy access to conductors without removing the entire raceway
• Cross-section of 3 inches by 1.5 inches accommodates multiple conductors or cable bundles
• Suitable for both low-voltage and line-voltage wiring applications where codes permit

Compatibility

Designed as an OEM-style surface raceway component compatible with the WIREMOLD V20 series raceway system for use in standard interior electrical installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements for surface metal or nonmetallic raceways. De-energize all circuits before pulling or terminating conductors within the raceway. Secure the base to the wall surface at intervals required by local code before snapping the cover into place. Do not exceed the conductor fill capacity defined by the raceway listing and applicable code tables.

Technical Specifications

• Length: 72.5 inches
• Width: 1.5 inches
• Height/Depth: 3 inches
• Weight: 3.7 pounds
• Color/Finish: Ivory
• UPC: 78677609328

Standard Information

• Brand: WIREMOLD
• Manufacturer Part Number: V20GB609
