Wipco TC20100ST Cpvc True Union Ball Check Valve 1 in

Product Description

The WIPCO TC20100ST is a 1-inch CPVC true union ball check valve designed for reliable backflow prevention in industrial and commercial flow control systems. Built with FPM o-rings and a square cut seat, it delivers positive sealing with minimum required back pressure. The true union design allows the valve body to be removed from the line without disturbing the end connections, simplifying inspection and maintenance. Rated at 235 PSI, this valve handles demanding service conditions and carries a Cv coefficient of 11.0, giving engineers and technicians a clear measure of flow capacity. Licensed plumbers and pipefitters are the typical installers.

This valve is suited for horizontal or vertical installation in industrial piping systems where backflow prevention is critical. The socket and threaded end connections provide flexible installation options for both solvent-welded and threaded CPVC piping arrangements. The true union configuration is especially practical in tight equipment rooms or chemical feed systems where inline serviceability matters. Applications include chemical processing, water treatment, and similar fluid handling systems that require a corrosion-resistant thermoplastic valve body.

Key Features

• CPVC construction for corrosion resistance in aggressive fluid service
• FPM o-rings provide chemical-compatible sealing
• Square cut seat ensures positive shutoff with low back pressure
• True union body design allows in-line removal without disturbing piping
• Dual end connection option: socket or threaded for installation flexibility
• 235 PSI pressure rating suitable for demanding flow control applications

Compatibility

Designed as an OEM-style replacement or new-installation true union ball check valve for 1-inch CPVC piping systems using socket or threaded end connections.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter familiar with thermoplastic piping systems and applicable plumbing codes. Depressurize and drain the line fully before removing or installing the valve. When using socket connections, follow the solvent cement manufacturer's cure time requirements before returning the line to service. The true union nuts should be hand-tightened and then snugged with a strap wrench only — do not use metal pipe wrenches directly on the valve body.

Technical Specifications

• Pipe Size: 1 inch
• Material: CPVC
• Sealing Material: FPM
• End Connection Type: Socket / Threaded
• Pressure Rating: 235 psi
• Cv Coefficient: 11.0

Standard Information

• Brand: WIPCO
• Manufacturer Part Number: TC20100ST
