Winters PWL2724 Cylinder Pressure Gauge 150 Psi Brass

Product Description

The WINTERS PWL2724 is a brass-case cylinder pressure gauge designed for monitoring gas cylinder and compressed-air line pressure in industrial and trade service applications. It features a 2-inch dial diameter with a display range of 0 to 200 psi and a maximum operating pressure of 150 psi. The bottom-mount 1/4-inch NPT connection allows direct installation into a cylinder valve or manifold port. The polycarbonate lens resists impact and keeps the dial face legible under field conditions. At 0.25 pounds, the gauge is compact and straightforward to install without specialized equipment.

This gauge is suited for use on compressed-gas cylinders, small compressed-air systems, and low-pressure fluid lines where a direct-mount bottom-connection gauge is required. It is appropriate for residential and light commercial service work involving compressed gases, welding supply lines, and similar low-to-medium pressure monitoring tasks. Licensed plumbers, HVAC technicians, and general trades personnel typically specify this type of gauge for service panel and cylinder valve applications.

Key Features

• 0 to 200 psi display range with 150 psi maximum operating pressure
• Bottom-mount 1/4-inch NPT connection for direct cylinder or manifold installation
• Brass case construction for durability in compressed-gas service environments
• Polycarbonate lens resists impact and maintains dial readability
• 3 percent accuracy rating for reliable pressure monitoring
• Compact 2-inch dial diameter and lightweight at 0.25 pounds

Compatibility

Designed as an OEM-style replacement or service gauge for compressed-gas cylinders and low-pressure systems equipped with a standard 1/4-inch NPT bottom-connection port.

Installation Notes

Installation should be performed by a qualified tradesperson following applicable codes, including ASME B40.100 guidelines for pressure gauge installation. Always depressurize and isolate the cylinder or line before removing or installing any pressure gauge. Apply thread sealant appropriate for the service gas or fluid to the NPT threads before installation. Do not exceed the 150 psi maximum operating pressure rating.
