Winters PPC5060-G. Pressure Gauge 0-30 Psi 4.5 in Dial

Product Description

The WINTERS PPC5060-G. is a glycerine-filled process industrial pressure gauge built for demanding fluid and gas monitoring applications. It features a 4.5-inch dual-scale analog dial with a 0 to 30 psi range and reads in both psi and an alternate scale. The thermoplastic case houses 316 stainless steel wetted parts and a stainless steel Bourdon tube, making it well-suited for corrosive media. Accuracy is rated at 0.5 percent of scale, meeting ANSI/ASME Grade 2A requirements. Licensed HVAC technicians, industrial plumbers, and process instrumentation technicians typically install and service this gauge.

This gauge fits process and industrial piping systems where a durable, liquid-filled instrument is required to dampen vibration and pulsation. The glycerine fill stabilizes the needle under dynamic line conditions, reducing wear on the Bourdon tube and improving readability. Lower mount configuration with a 0.5-inch NPT male connection allows direct in-line or panel-bottom installation. The polycarbonate lens and IP65-rated thermoplastic case protect the internals in wet or wash-down environments. Operating temperature range is -40 degrees F to 250 degrees F, which covers most hydronic, compressed air, water, and light chemical service installations.

Key Features

• Glycerine-filled for vibration and pulsation dampening on active process lines
• 316 stainless steel Bourdon tube and wetted parts resist corrosion from process media
• 0.5 percent of scale accuracy meets ANSI/ASME Grade 2A and ASME B40.100 standards
• 4.5-inch dual-scale analog dial improves readability at a distance
• IP65-rated thermoplastic case with polycarbonate lens for wet and wash-down environments
• Wide operating range of -40 degrees F to 250 degrees F suits diverse service conditions

Compatibility

Designed as an OEM-style process pressure gauge for industrial and commercial piping systems requiring a lower-mount, 0.5-inch NPT connection with a 4.5-inch dial and a 0 to 30 psi measurement range.

Installation Notes

Installation should be performed by a licensed plumber or instrumentation technician familiar with the process system pressure and media involved. Shut off and bleed down the process line to zero pressure before connecting or removing any pressure gauge. Apply thread sealant or PTFE tape to the NPT threads per applicable IPC or facility piping standards, and do not over-torque the fitting to avoid cracking the thermoplastic case. Verify the glycerine fill is intact and the lens is undamaged before returning the system to service.
