WINCO 205014-171 50kW PTO Generator

Brand: WINCO
SKU: 205014-171
Availability: Out Of Stock
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The WINCO 205014-171 is a 50kW PTO driven generator, designed to provide a dependable three-phase 120/240V power source for various applications. It features a 1000 RPM gearcase, ensuring efficient performance. The unit is equipped with an automatic voltage regulator (AVR) for stable voltage output, along with multiple receptacles for effective power distribution. A 1 3/8 6-spline PTO shaft enables easy connection to a tractor, enhancing usability.

  • Provides 120/240V three-phase power.
  • Equipped with a 1000 RPM gearcase.
  • Features a 1 3/8 6-spline PTO shaft.

Product Highlights

This generator is load tested before leaving the factory to ensure reliability and functionality for users.

Product Information

Standard Information

  • Manufacturer: Winco
  • MPN: 205014-171
Technical Specifications
Power Type
Conventional
Phase AC
3PH
Voltage VAC
120/240
Frequency Hz
60
Standby Watts
50000
Continuous Watts
42000
Standby Amps
120 @ 1.0 PF / 150 @ 0.8 PF
Continuous Amps
101 @ 1.0 PF / 126 @ 0.8 PF
Voltage Regulation
AVR
PTO Input Speed
1000 RPM
PTO Shaft
1 3/8 6-spline
Input HP
100 hp
120V Receptacles
(2) NEMA 5-20 20A
240V Receptacles
(1) NEMA 6-50R 50A
Anderson Connector
175 Amps
Dimensions
41 x 20 x 27 inches
Weight
680 lbs
Warranty
3 years
