Williams JHW7-626 Socket, 2 1/8 In OAL, SAE, Shallow Impact, 1 In Dr, 13/16 In

Product Description

The WILLIAMS JHW7-626 socket is a shallow impact socket with a 1-inch drive size and a 13/16-inch size. It has an overall length of 2 1/8 inches and a black industrial finish. This socket is suitable for use with pneumatic and electric impact wrenches and designed for maximum engagement on 6 point fasteners.

• Socket Type: Shallow Impact
• Drive Size: 1 Inch
• Size: 13/16 Inch

Product Highlights

This shallow impact socket is heat treated for long life, safety, and durability. It features SUPERTORQUE lobular openings for greater turning power.

Product Information

Standard Information

• Brand: WILLIAMS
• Manufacturer Part Number: JHW7-626
• Country of Origin: US

Technical Specifications

• MPN: JHW7-626
• ItemID: SNP7626
• DisplayName: SNP7-626
• UPCCode: 662459257215
• Manufacturer: Williams
• Brand: Williams
• UOM: Each
• PurchaseDescription: Socket, 2 1/8 Inch OAL, Shallow, 1 Inch Dr, 13/16 Inch Size
• ProductCategory: Hand Tools
• ProductSegment: Sockets & Accessories
• ProductLine: Sockets
• Length: 2.2
• Width: 2.2
• Height: 2.2
• Socket Type: Shallow Impact
• Drive Size: 1 Inch
• Size: 13/16 Inch
• Overall Length: 2 1/8 Inch
• Finish: Black Industrial
• Socket Shape: 6 Point
• Drive End Diameter: 2 1/8 Inch
• Working End Diameter: 1 7/16 Inch
• Length Type: Shallow
• Bolt Clearance Depth: 15/16 in
• Socket Drive Size: 1 in
• No. of Points: 6
• Socket Size: 13/16 in
• Bolt Clearance: 3/4 in
• Opening Configuration: 6 Point
• Product Type: Shallow Sockets
• Size, inches: 13/16
• Dimension A, Overall Length, inches: 2-1/8
• Dimension B, Drive End Diameter, inches: 2-1/8
• Dimension C, Working End Diameter, inches: 1-7/16
• Dimension D, Broach Depth, inches: 11/16
• Bolt Clearance Diameter, inches: 3/4
• Dimension F, Nose Length, inches: 7/8
• Uses RET RING® Number: 7-2XS
• Use O-Ring/Pin: 7-1B/7-2D
• Number of points: 6
• System of Measurement: SAE
• Primary Material: Steel
• ANSI Number: B107.2
• Style: Shallow Length
• Case Quantity: 1 each
• Package Quantity: 1 per pack
