Williams JHW6M-624A 24MM Metric Shallow Impact Socket 3/4 Dr

Product Description

The WILLIAMS COMFORT PRODUCTS JHW6M-624A is a metric shallow impact socket designed for heavy-duty fastener work in professional trade environments. Built on a 3/4 inch drive, this socket measures 2 inches in overall length and fits 24 MM fasteners. The lobular internal geometry delivers greater turning power without deforming fastener heads, and the steel construction is specially heat treated to withstand the repeated stress cycles of pneumatic and electric impact wrenches. Electricians, millwrights, pipefitters, and mechanical contractors reach for this type of socket when working in confined spaces where a standard-depth socket will not clear surrounding hardware.

This shallow impact socket is suited for metric fastener applications across industrial, commercial, and heavy mechanical service settings. Its compact profile makes it a practical choice when bolt depth is limited or when clearance between the fastener and surrounding structure is tight. The drive end includes a pin retention hole and groove, allowing use of a retaining pin or hog ring to secure the socket to the impact wrench anvil during high-vibration operation. Sold individually, it integrates into existing 3/4 inch drive impact sets.

Key Features

• SUPERTORQUE lobular openings apply force to fastener flats, reducing rounding and deformation
• Designed for maximum engagement on 6-point fasteners
• Compatible with pneumatic and electric impact wrenches
• Specially heat treated for impact service, extending service life under high-torque cycling
• Drive end features pin retention hole and groove for positive socket-to-anvil retention
• Shallow profile allows use in restricted-clearance locations

Compatibility

Designed as an OEM-style impact socket for use with 3/4 inch drive pneumatic and electric impact wrenches accepting standard 3/4 inch drive accessories in metric 24 MM applications.

Installation Notes

Installation and removal of this socket is typically performed by licensed mechanics, millwrights, pipefitters, or other trade professionals working with impact drive equipment. Before use, ensure the impact wrench is depressurized or powered down when attaching or removing the socket. Confirm the retention pin or ring is properly seated in the drive-end groove before operating the wrench to prevent socket ejection under load. Inspect the socket for cracks or deformation before each use, and remove from service if any damage is found.

Technical Specifications

• Drive Size: 3/4 inch
• Fastener Size: 24 MM
• Measurement Standard: Metric
• Socket Type: Shallow Impact
• Point Count: 6 point
• Overall Length (OAL): 2 inches
• Width: 2 inches
• Height: 1.6 inches
• Weight: 0.68 pounds
• Sold As: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: JHW6M-624A
