Williams Comfort Products TS-3 Digital Wall Thermostat

Product Description

The WILLIAMS COMFORT PRODUCTS TS-3 is a wired digital wall thermostat designed for use with gas hearth heaters and direct vent gravity systems. It features an easy-to-read LCD screen that displays the current room temperature in either Fahrenheit or Celsius. The thermostat is battery operated, allowing for straightforward wall-mounted installation without the need for a dedicated power wire. Operation range spans 45 to 99 degrees F, covering typical residential comfort settings. Licensed HVAC technicians and heating specialists are the primary installers for this type of control device.

This thermostat is intended for use with Monterey, Direct Vent Gravity, and Console Hearth Heater models. It provides three operating modes: Thermostat mode, Manual On, and Manual Off, giving the installer and end user flexible control options. Wall-mounted installation keeps the unit at an accessible height for straightforward temperature adjustment. This product is manufactured by Skytech and sourced through Williams Comfort Products.

Key Features

• LCD screen displays room temperature in Fahrenheit or Celsius
• Battery operated — no dedicated power wire required
• Three control modes: Thermostat, Manual On, and Manual Off
• Operation range of 45 to 99 degrees F
• Wall-mounted design for accessible placement

Compatibility

Designed for use with Monterey, Direct Vent Gravity, and Console Hearth Heaters as specified by the manufacturer.

Installation Notes

Installation should be performed by a licensed HVAC technician or qualified heating professional. Shut off the heater and disconnect power before beginning any wiring or mounting work. Follow the heater manufacturer's wiring diagram and all applicable local mechanical and electrical codes. Install fresh batteries before commissioning the thermostat to ensure accurate temperature readings.

Technical Specifications

• Display: LCD screen
• Temperature Display: Fahrenheit or Celsius
• Operation Range: 45 to 99 degrees F
• Power Source: Battery operated
• Mounting: Wall mounted
• Control Modes: Thermostat, Manual On, Manual Off

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: TS-3
