Williams Comfort Products QYX22A Torque Wrench Head

Product Description

The WILLIAMS COMFORT PRODUCTS QYX22A is an 11/16-inch torque wrench head designed for precision fastening in demanding trade applications. It features a 15-degree offset box end configuration with a 12-point design, allowing access to fasteners in tight or restricted spaces. The shank measures 0.560 inches and uses a Y-type shank interface for secure attachment to compatible torque wrench handles. Maximum torque capacity is 160 foot-pounds, making it suitable for heavy-duty bolting tasks across HVAC, plumbing, and mechanical service work. Licensed technicians and journeymen mechanics rely on this type of head for controlled torque application where a standard wrench cannot fit.

This torque wrench head is suited for residential and commercial service environments where access to fasteners is limited. The 15-degree offset box end allows the tool to clear obstructions while maintaining full engagement on the fastener. It is commonly used during equipment installation, compressor service, and mechanical assembly tasks that require calibrated torque output. The 12-point socket design provides multiple engagement positions, reducing the need for wide swing clearance in confined areas.

Key Features

• 11/16-inch drive size for SAE fastener compatibility
• 15-degree offset box end head for clearance in tight spaces
• 12-point design allows multiple engagement positions with minimal swing arc
• Y-type shank interface for secure wrench handle connection
• Maximum torque rating of 160 foot-pounds for heavy-duty applications
• Compact profile: 3.9 inches long, 0.9 inches height, 0.6 inches width

Compatibility

Designed for use with compatible Y-shank torque wrench handles accepting a 0.560-inch shank. Verify handle compatibility before use.

Installation Notes

This torque wrench head should be installed and used by qualified tradespeople familiar with calibrated torque tools. Confirm the shank is fully seated and secured in the handle before applying load. Do not exceed the 160 foot-pound maximum torque rating. Inspect the head for wear or damage before each use and replace if cracking or rounding is observed.

Technical Specifications

• Size: 11/16 inch
• Head Type: 15 Degree Offset Box End
• Point Type: 12 Point
• Shank Size: 0.560 inches
• Shank Type: Y
• Maximum Torque: 160 foot-pounds
• Length: 3.9 inches
• Width: 0.6 inches
• Height: 0.9 inches
• Weight: 0.17 pounds
• Standard: SAE
• UOM: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: QYX22A
