Williams Comfort Products QXX64A Torque Wrench Head 2 in

Product Description

The WILLIAMS COMFORT PRODUCTS QXX64A is a 2-inch, 15-degree offset box end torque wrench head designed for high-torque fastening applications in trade and industrial settings. It features a 12-point configuration and accepts a 0.735-inch X-type shank, making it compatible with standard drive torque wrench handles. With a maximum torque rating of 240 ft-lb, this head is suited for heavy-duty bolted connections where precise torque application is required. Licensed mechanics, pipefitters, millwrights, and industrial technicians rely on offset box end heads like this when clearance constraints prevent use of a straight-drive tool.

This torque wrench head is intended for SAE fastener sizes in mechanical, industrial, and heavy equipment service environments. The 15-degree offset provides clearance in confined spaces where a standard inline head cannot seat properly on the fastener. Typical applications include flange bolting, equipment assembly, and structural fastener torquing in both shop and field conditions. It is sold individually and is appropriate for professional use where controlled torque values are required by specification or code.

Key Features

• 2-inch 12-point box end for SAE fastener engagement
• 15-degree offset head geometry for clearance in tight spaces
• 0.735-inch X-type shank for secure drive handle connection
• Maximum torque capacity of 240 ft-lb
• Compact profile at 6 inches length and 1 inch height

Compatibility

Designed for use with torque wrench handles accepting a 0.735-inch X-type shank. Verify shank compatibility with your existing drive handle before installation.

Installation Notes

This head is installed by a qualified mechanic or technician onto a compatible torque wrench handle. Ensure the shank is fully seated and locked before applying torque. Do not exceed the 240 ft-lb maximum torque rating. Follow applicable equipment manufacturer torque specifications and relevant industry standards when fastening critical joints.

Technical Specifications

• Head Size: 2 inches
• Head Type: 15 Degree Offset Box End
• Point Type: 12 Point
• Shank Size: 0.735 inches
• Shank Type: X
• Maximum Torque: 240 ft-lb
• Length: 6 inches
• Width: 2.8 inches
• Height: 1 inch
• Weight: 0.53 pounds
• Drive Standard: SAE
• Sold As: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: QXX64A
