Williams Comfort Products QXX40A Torque Wrench Head 1-1/4 in

Product Description

The WILLIAMS COMFORT PRODUCTS QXX40A is a torque wrench head designed for use with compatible torque wrench handles that accept an X-shank drive. It features a 15-degree offset box end configuration with a 12-point socket profile sized at 1-1/4 inches, making it suited for fastener access in tight or angled spaces. The shank measures 0.735 inches in diameter and is rated for a maximum torque of 240 ft-lb. This head is an SAE-standard tool installed by mechanics, HVAC technicians, plumbers, and other trade professionals who require precision torque application in confined work areas.

This torque wrench head is used wherever a standard inline torque wrench cannot reach due to clearance restrictions. The 15-degree offset angle allows the tool to engage fasteners at an angle, which is useful in equipment rooms, mechanical chases, and tight equipment bays. It is sold individually and is appropriate for both residential and light commercial service work where 1-1/4-inch SAE fasteners require controlled torque values up to 240 ft-lb.

Key Features

• 1-1/4-inch SAE 12-point box end for broad fastener contact and reduced rounding risk
• 15-degree offset head angle improves access in restricted or obstructed work spaces
• X-shank drive with 0.735-inch shank diameter for compatibility with matching torque wrench handles
• Rated to 240 ft-lb maximum torque for heavy fastener applications
• Sold as an individual head unit for targeted tool kit additions

Compatibility

Designed for use with torque wrench handles that accept the X-shank drive interface. Verify shank specification on the wrench handle before installation.

Installation Notes

This tool is used by licensed trade professionals and qualified mechanics performing controlled torque procedures. Confirm that the torque wrench handle is rated to handle the maximum torque of this head before use. Do not exceed the rated 240 ft-lb maximum torque. Inspect the shank fit and ensure secure seating before applying load.

Technical Specifications

• Head Size: 1-1/4 inches
• Head Type: 15 Degree Offset Box End
• Point Type: 12 Point
• Maximum Torque: 240 ft-lb
• Shank Size: 0.735 inches
• Shank Type: X
• Standard: SAE
• Length: 1 inch
• Width: 5.6 inches
• Height: 1.7 inches
• Weight: 0.9 pounds
• Sold As: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: QXX40A
