Williams Comfort Products QXX38A Torque Wrench Head

Product Description

The WILLIAMS COMFORT PRODUCTS QXX38A is a 1 3/16 inch offset box end torque wrench head designed for high-torque fastening applications in mechanical, industrial, and trade service environments. The head features a 15-degree offset box end configuration with a 12-point contact pattern, allowing engagement in tight or obstructed spaces where a standard torque wrench cannot reach. The shank measures 0.735 inches with an X-type shank drive, and the head is rated for a maximum torque of 240 foot-pounds. At 0.83 pounds, it is a compact and purpose-built interchange head for use with compatible torque wrench handles.

This torque wrench head is suited for mechanical technicians, HVAC installers, plumbers, and industrial maintenance professionals who need precise torque application in confined or angled fastening situations. The 15-degree offset allows the fastener to be driven at an angle relative to the wrench handle, which is useful when working around obstructions such as conduit, piping, or structural members. The 12-point box end design provides multiple engagement positions for faster socket placement in restricted access areas.

Key Features

• 1 3/16 inch box end opening for fasteners of that specified size
• 15-degree offset head angle for access in obstructed or tight spaces
• 12-point contact pattern for multiple engagement positions
• X-type shank drive with 0.735 inch shank diameter for compatible torque wrench handles
• Rated to 240 foot-pounds maximum torque
• Compact form factor at 0.83 pounds

Compatibility

Designed as a replacement or supplemental torque wrench head for use with X-shank torque wrench handles that accept a 0.735 inch shank drive. Confirm handle compatibility before installation.

Installation Notes

Installation of this torque wrench head should be performed by a qualified mechanic or trade professional familiar with torque wrench systems. Ensure the shank is fully seated and secured in the torque wrench handle before applying load. Do not exceed the 240 foot-pound rated maximum torque for this head. Inspect the head and shank interface for wear or damage before each use.

Technical Specifications

• Head Size: 1 3/16 inches
• Head Type: 15 Degree Offset Box End
• Point Type: 12 Point
• Shank Size: 0.735 inches
• Shank Type: X
• Maximum Torque: 240 foot-pounds
• Length: 1.7 inches
• Width: 5.5 inches
• Height: 0.7 inches
• Weight: 0.83 pounds

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: QXX38A
