Williams Comfort Products JHWISSX930 Flextension Extension

Product Description

The WILLIAMS COMFORT PRODUCTS JHWISSX930 is a Flextension drive extension with an integrated 15/16 inch socket on a 1/2 inch drive. The socket and extension are permanently joined in a single non-removable unit, eliminating the risk of the socket separating from the extension during use. This design is built for engine and heavy equipment manufacturing, assembly, and repair environments where continuous, uninterrupted operation is critical. The socket opening uses a SUPERTORQUE lobular profile to deliver greater turning power while reducing deformation of the fastener head. Maximum working torque is rated at 160 ft-lbs. Licensed tradespeople and assembly technicians in production and repair settings are the primary installers.

This Flextension is designed for use on hand tools and power tools including impulse and direct-drive tools. It is NOT rated for impact tool use. The tool accommodates up to a 30-degree angle offset, making it useful in tight or angled access situations common in engine bays and heavy equipment frames. The drive end includes a 7/32 inch cross hole bevel for ease of positioning and engagement.

Key Features

• Integrated non-removable socket and extension design prevents disconnection during operation
• SUPERTORQUE lobular socket opening increases turning power without deforming fasteners
• Maximum working torque: 160 ft-lbs / 1920 in-lbs / 217 Nm
• Up to 30-degree angle offset for use in restricted or angled access areas
• Socket retention pin is TIG welded for full rotation power transfer
• Drive end features a 7/32 inch cross hole bevel for easy positioning
• Durable black oxide finish
• Made in the U.S.A.

Compatibility

Designed for use with hand tools and power tools (impulse or direct drive) using a 1/2 inch drive. Not compatible with impact tools.

Installation Notes

This tool is intended for use by qualified mechanics and assembly technicians in hand-tool and direct-drive power-tool applications. Do not use with impact drivers or impact wrenches, as this tool is not rated for impact use. Ensure the drive end is fully seated in the tool before applying torque. Follow all applicable equipment manufacturer torque specifications for the fasteners being serviced.

Technical Specifications

• Drive Size: 1/2 inch
• Socket Size: 15/16 inch
• Maximum Working Torque: 160 ft-lbs / 1920 in-lbs / 217 Nm
• Angle Offset: Up to 30 degrees
• Drive End Cross Hole Bevel: 7/32 inch
• Finish: Black Oxide
• Weight: 0.7 pounds
• Country of Origin: USA

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: JHWISSX930
