Williams Comfort Products JHW6-628A Shallow Impact Socket

Product Description

The WILLIAMS COMFORT PRODUCTS JHW6-628A is a 3/4 inch drive shallow impact socket designed for use with pneumatic and electric impact wrenches. Built to SAE spec at 7/8 inch, it features a 2 inch overall length and lobular internal geometry that transfers torque evenly across fastener flats. The socket is specially heat treated for impact service, giving it the durability and toughness needed for repetitive high-torque applications in the field or shop. It is sold individually and suited for professional trade use where a shallow-profile socket is required.

This socket fits into heavy equipment maintenance, fleet repair, industrial assembly, and general mechanical service where 3/4 inch drive tooling is standard. The shallow overall length makes it practical in tight clearance situations where a deep socket will not seat properly. Technicians working on fasteners that are accessible but have limited axial clearance will find this profile useful. The SAE 7/8 inch size covers a wide range of standard fastener applications common in commercial and industrial environments.

Key Features

• SUPERTORQUE lobular openings distribute load across fastener flats to reduce deformation and rounding
• Engineered for maximum engagement on 6-point fasteners
• Compatible with pneumatic and electric impact wrenches
• Specially heat treated for impact service to extend service life and maintain structural integrity
• Shallow profile suits applications with limited axial clearance
• 3/4 inch drive accepts standard heavy-duty impact wrench anvils

Compatibility

Designed as an OEM-style impact socket for use with 3/4 inch drive pneumatic and electric impact wrenches requiring SAE shallow sockets.

Installation Notes

Installation and removal of sockets should be performed with the impact wrench fully depressurized or powered down before changing tooling. Confirm the socket is fully seated on the drive anvil and the retaining pin or ring is engaged before applying torque. Impact sockets are not rated for use with torque wrenches and should not substitute for standard chrome sockets in torque-critical applications. Inspect the socket for cracks or deformation before each use and remove from service if damage is found.

Technical Specifications

• Drive Size: 3/4 inch
• Socket Size (SAE): 7/8 inch
• Overall Length (OAL): 2 inches
• Profile: Shallow
• Point Count: 6 point
• Measurement Standard: SAE
• Weight: 0.73 pounds
• Width: 2 inches
• Height: 1.8 inches
• Sold As: Each
• UPC: 662459662828

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: JHW6-628A
