Williams Comfort Products HS10K Hydraulic Flange Spreader

Product Description

The WILLIAMS COMFORT PRODUCTS HS10K is a hydraulic flange spreader designed for heavy-duty industrial maintenance work. It delivers 10,000 lbs of spreading force per unit and opens flanges to a 3-inch gap in a single pass, starting from an insertion gap of just 3/16 inches. The jaws open in parallel, feature a serrated gripping surface, and hold position without drifting. Safety blocks are included. Weighing 20.87 pounds, the HS10K is light enough for one-person operation. It is intended for use by maintenance mechanics and industrial trades across a broad range of piping and mechanical service applications.

The HS10K is suited for a wide range of maintenance tasks in industrial and commercial environments. Common applications include gasket replacement, vessel opening, lifting and leveling, load alignment, blind turning, bearing and impeller removal, manway separation, and toe jack operations. Its one-size-fits-all design means a single tool covers multiple jobs on the same work order, reducing the number of specialty tools required on site.

Key Features

• 10,000 lbs of hydraulic spreading force per spreader
• Opens to a 3-inch gap in a single pass from a 3/16-inch insertion gap
• Parallel-opening jaws with serrated surface grip and hold position
• No loose wedges or separate parts to manage in the field
• Lightweight at 20.87 pounds — rated for single-person operation
• Safety blocks included for added security during spreading operations

Compatibility

Designed as a universal hydraulic flange spreader with a one-size-fits-all jaw configuration suitable for a wide range of flange types and sizes encountered in industrial piping and mechanical maintenance.

Installation Notes

Installation and operation should be performed by qualified maintenance mechanics or industrial trades personnel familiar with hydraulic tooling and flange service procedures. Before inserting the tool, isolate and depressurize the system being serviced and follow applicable lockout/tagout procedures. Use the included safety blocks whenever the spreader is under load to prevent uncontrolled movement. Never exceed the rated spreading force of the tool.

Technical Specifications

• Spreading Force: 10,000 lbs per spreader
• Maximum Gap: 3 inches
• Minimum Insertion Gap: 3/16 inches
• Weight: 20.87 pounds
• Unit of Measure: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: HS10K
