Williams Comfort Products 8H3838D20 Gas Connector 20 Ft

Product Description

The WILLIAMS COMFORT PRODUCTS 8H3838D20 is a flexible gas connector designed for use in residential and light commercial heating appliance installations. With a 0.38 inch inner diameter and 3/8 inch NPTF threaded end fittings, this 20-foot connector provides the flexible gas supply line needed to connect appliances such as wall heaters, space heaters, and similar gas-fired equipment to a dedicated supply line. At 7.099 pounds, this is a substantial, full-length connector suited for applications where a longer flexible run is required between the gas shutoff valve and the appliance inlet.

This connector is appropriate for residential and light commercial gas appliance hookups where a flexible, code-compliant gas supply line is required. The 20-foot length accommodates installations where the appliance is located at a distance from the nearest gas outlet or shutoff, reducing the need for additional rigid pipe runs. It is typically installed by licensed plumbers or gas fitters working on natural gas or LP appliance connections.

Key Features

• 0.38 inch inner diameter for consistent gas flow to connected appliances
• 3/8 inch NPTF threaded fittings for secure, leak-resistant connections
• 20-foot length provides flexibility in appliance placement and routing
• Sold individually, making it easy to specify exact quantities per job

Compatibility

Designed as an OEM-style flexible gas connector for residential and light commercial gas-fired heating appliances requiring a 3/8 inch NPTF supply connection.

Installation Notes

Installation must be performed by a licensed plumber or gas fitter in accordance with local codes and the applicable provisions of the IFGC. Shut off the gas supply at the main valve and verify zero pressure before making or breaking any connections. Apply thread sealant rated for gas service to all NPTF fittings and leak-test all connections with an approved gas leak detection solution after installation. Do not bend the connector beyond its minimum bend radius or route it through walls, floors, or ceilings.

Technical Specifications

• Inner Diameter: 0.38 inches
• End Connection: 3/8 inch NPTF
• Length: 20 feet
• Weight: 7.099 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 1
• UPC: 662459945983

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: 8H3838D20
