Williams Comfort Products 6C55T06 Single Acting Cylinder

Product Description

The WILLIAMS COMFORT PRODUCTS 6C55T06 is a single acting cylinder with a 6 inch stroke, designed for use in pneumatic actuation systems found in HVAC and building automation applications. Single acting cylinders use air pressure to move the actuator in one direction, with a return spring providing the opposing stroke. This design simplifies pneumatic control circuits and reduces the number of air supply connections required. At 57.452 pounds, the 6C55T06 is a substantial unit suited for heavy-duty actuation tasks. Licensed HVAC technicians and building controls specialists are the typical installers for this type of pneumatic actuator component.

The 6C55T06 is applied in commercial and industrial HVAC control systems where pneumatic actuators drive dampers, valves, or other controlled devices. The 6 inch stroke makes it appropriate for larger damper or valve assemblies requiring extended travel. This cylinder is typically part of a pneumatic control loop operating on low-pressure compressed air supply, common in older commercial building automation systems and retrofit pneumatic control applications.

Key Features

• Single acting design uses air pressure for one direction of travel with spring return
• 6 inch stroke for extended actuator travel on larger dampers or valves
• Substantial 57.452 pound construction indicating heavy-duty build quality
• Sold individually (each unit) with a minimum order quantity of one

Compatibility

Designed as an OEM-style replacement or direct application component for pneumatic HVAC actuation systems using the Williams 55T cylinder series configuration.

Installation Notes

Installation should be performed by a qualified HVAC technician or building controls specialist familiar with pneumatic control systems. Shut off the compressed air supply and depressurize the pneumatic line before removing or installing the cylinder. Verify that mounting hardware and air fittings are rated for the operating pressure of the pneumatic control circuit. Consult applicable mechanical and HVAC codes for guidance on pneumatic system service procedures.

Technical Specifications

• Stroke Length: 6 inches
• Actuation Type: Single Acting
• Weight: 57.452 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 1
• UPC: 662459922946

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: 6C55T06
