Wilkins 70XLDU1 70XL Pressure Reducing Valve 1 Inch Double Union Fnpt Cast Bronze Lead Free

Product Description

The Wilkins 70XLDU1 is a lead-free pressure reducing valve from the trusted 70XL series. It is designed for potable water systems in residential and commercial plumbing applications. Plumbers and mechanical contractors rely on pressure reducing valves to protect downstream piping, fixtures, and equipment from high inlet pressure. The 70XLDU1 steps down incoming supply pressure to a safe, consistent level, extending the life of appliances and preventing pipe stress. This valve carries a 1 inch nominal size with a double union female national pipe thread end style, making installation and in-line service straightforward without cutting into the line. The cast bronze body is a proven choice for plumbing service because it resists corrosion and holds up under continuous water contact. Trim components including the seat, stem, and sleeve are machined from 300 stainless steel, which adds durability and corrosion resistance in the flow path. Elastomers are Buna Nitrile and EPDM, both well-suited for water service across a broad range of temperatures. The valve is rated for water service up to 140 degrees F and handles system pressures up to 300 psi on the inlet side. Inlet to outlet length measures 5 and 7 eighths inches, and the overall height is 6 and 11 sixteenths inches, keeping the unit compact enough for tight mechanical rooms and utility closets. This is a domestically produced unit, meeting standards that many commercial and municipal specifications require. HVAC and plumbing contractors installing hydronic heating systems, domestic water services, or irrigation supply lines will find the 70XLDU1 a reliable, code-compliant solution for pressure management. The double union configuration allows the valve body to be removed from the line quickly for inspection or replacement without disturbing the surrounding piping, reducing service downtime on the job.

• Lead-free cast bronze body meets potable water requirements for commercial and residential plumbing systems
• Double union FNPT end style allows fast in-line removal and reinstallation without cutting pipe
• 300 stainless steel seat, stem, and sleeve trim delivers long-term corrosion resistance in continuous water service

Product Highlights

The Wilkins 70XLDU1 pressure reducing valve combines a durable lead-free cast bronze body with serviceable double union connections, making it a dependable and easy-to-maintain choice for water pressure control in commercial and residential plumbing systems.

Product Information

Standard Information

• Brand: WILKINS
• Manufacturer Part Number: 70XLDU1

Technical Specifications

• Series: 70XL
• Nominal Size: 1 inch
• End Style: Double Union FNPT
• Body Material: Cast Bronze
• Trim Material: 300 Stainless Steel Seat, Stem, and Sleeve
• Softgoods Material: Buna Nitrile and EPDM Elastomers
• Pressure Range: 300 psi
• Temperature Rating: 140 degrees F
• Inlet to Outlet Length: 5 and 7 eighths inches
• Height: 6 and 11 sixteenths inches
• Media: Water
• Domestic or Import: Domestic
