Wilkins 600XLC34 Pressure Reducing Valve with Integral By-pass Check Valve and Strainer 3/4 Inches Female C Union X Fnpt 300 Psi Cast Bronze

Product Description

The Wilkins 600XLC34 is a lead-free pressure reducing valve designed for residential and light commercial water supply systems. It belongs to the 600XL Series and includes an integral by-pass check valve and strainer built directly into the valve body. This combination makes it a reliable single-component solution for controlling downstream water pressure while protecting the system from backflow and debris. HVAC technicians, plumbers, and mechanical contractors use this type of valve to regulate city water pressure down to safe working levels for building plumbing, hydronic heating systems, radiant floor systems, and potable water applications. The 600XLC34 has a 3/4 inch nominal pipe size with a Female C Union inlet connection and a Female NPT outlet connection. This dual connection style makes installation and future service easier because the union end allows the valve to be removed without cutting pipe. The cast bronze body provides strong corrosion resistance in water service environments and meets lead-free compliance standards required for potable water contact. The seat trim is 300 stainless steel, which resists wear and maintains a consistent seal over long service cycles. Internal softgoods include Buna Nitrile and EPDM elastomers, natural vulcanized fiber, and an Acetal cap gasket for reliable sealing performance. The valve is rated to 300 psi and handles water temperatures up to 140 degrees Fahrenheit. The overall height is 5.5 inches and the inlet to outlet length is 5.3125 inches, making it compact enough for tight mechanical spaces. The integrated strainer catches particulates before they reach downstream components, reducing maintenance calls and protecting fixtures, valves, and equipment from sediment damage. This valve is a practical, code-compliant choice for new construction and retrofit plumbing projects.

• Lead-free cast bronze body rated for potable water service and corrosion-resistant in standard water supply applications
• Integral by-pass check valve and strainer built in to reduce required components and simplify installation
• Female C Union x FNPT connections allow easy removal and reinstallation without cutting pipe

Product Highlights

The Wilkins 600XLC34 delivers pressure regulation, backflow protection, and straining in one compact lead-free bronze valve. Its union inlet and NPT outlet connections are designed for straightforward installation and serviceability in residential and commercial plumbing systems.

Product Information

Standard Information

• Brand: WILKINS
• Manufacturer Part Number: 600XLC34

Technical Specifications

• Series: 600XL
• Nominal Size: 3/4 inches
• End Style: Female C Union x FNPT
• Body Material: Cast Bronze
• Trim Material: 300 Stainless Steel Seat
• Softgoods Material: Buna Nitrile and EPDM Elastomers, Natural Vulcanized Fiber, Acetal Cap Gasket
• Pressure Range: 300 psi
• Temperature Rating: 140 degrees F
• Media: Water
• Height: 5.5 inches
• Inlet to Outlet Length: 5.3125 inches
