Wilkins 600XL3-34 Pressure Reducing Valve 3/4 inches 600XL3-34

Product Description

The WILKINS 600XL3-34 pressure reducing valve is designed for installation on potable water lines to reduce high inlet pressure to a lower outlet pressure. The integral strainer makes this device suitable for residential and commercial water systems requiring frequent cleaning. It protects plumbing systems and reduces water consumption.

• Lead Free
• Cast Bronze
• Union FNPT

Product Highlights

This pressure reducing valve controls incoming water pressure to set levels. Its direct acting integral by-pass design prevents buildup of excessive system pressure caused by thermal expansion.

Product Information

Standard Information

• Brand: WILKINS
• Manufacturer Part Number: 600XL3-34
• Country of Origin: Switzerland

Technical Specifications

• Size: 3/4"
• Max Temp (F): 140°F
• Max Inlet Pressure: 300 PSI
• Lead Free: Yes
• Application: Light Commercial Use; Residential Use
• Material: Cast Bronze
• Height: 7"
• Inlet Type: Union FNPT
• Outlet Type: FNPT
• Brand: WILKINS
• For Media: Water
• Connections: FNPT x FNPT
• Inlet Connection Size: 3/4 in
• Outlet Connection Size: 3/4 in
• Body Material: Brass
• Stem Material: Stainless Steel
• Pressure Adjustment Range: 15 psi to 75 psi
• Operating Pressure Range: 15 psi to 400 psi
• Max. Operating Temperature: 140 °F
• Factory Set Pressure: 50 psi
• Max. Continuous Flow Rate: 25 gpm
• Max. Intermittent Flow Rate: 33 gpm
• Port Design: Full Port
• Overall Width: 1-3/4 in
• Overall Height: 6-1/4 in
• Includes Strainer: Strainer Included
• Low-Lead Compliance: Low-Lead Compliant
• NSF Certifications for Food and Drinking Water: NSF 61; NSF 372
• Standards: CSA® Certified; cUPC® Listed; is ASSE® Listed; NSF/ANSI/CAN 61 and 372
• Manufacturer Part Number: 34-600XL3
