Product Description
The Wilkerson R30-06-000 is a robust air regulator designed for reliable and precise pressure regulation in industrial settings. Offering a maximum flow rate of 470 CFM and an operating pressure up to 300 PSI, this regulator is an essential component for high-performance air systems.
- Efficient pressure adjustment from 10 to 125 PSI
- Durable zinc body with a nitrile seal ensures longevity and resilience in challenging environments
- Easy installation with 3/4 inch NPT female inlet and outlet ports
Product Highlights
Constructed for industrial use, the Wilkerson R30-06-000 provides excellent control over compressed air systems within a compact frame, ensuring efficient operation and minimal pressure loss.
Product Information
Standard Information
-
Brand: Wilkerson
-
Part Number: R30-06-000
Technical Specifications
-
Maximum Flow Rate: 470 CFM
-
Maximum Operating Pressure: 300 PSI
-
Overall Width: 4.3 inches
-
Pressure Adjustment: Knob
-
Operating Temperature Range: 32 to 150 degrees Fahrenheit
-
Body Material: Zinc
-
System Location: Air Line
-
Air Outlet Type: NPT
