Wilkerson R28-06-F000B Air Regulator 3/4 Npt 300 Psi

Product Description

The WILKERSON R28-06-F000B is a standard compressed air regulator designed to maintain consistent downstream pressure in pneumatic systems. Built with an aluminum die cast body, it handles supply pressures up to 300 psi and delivers a maximum air flow of 233 CFM through a 3/4-inch NPT port. The unit includes a relief function to vent excess pressure and features a 1/4-inch gauge port for field-installed monitoring. It is part of the Series 28 modular product line, allowing it to connect directly with compatible filter and lubricator units. Industrial maintenance technicians and pneumatic system installers are the primary users of this regulator.

This regulator is suited for compressed air distribution applications in industrial, commercial, and manufacturing environments. It fits inline on air supply lines where stable regulated pressure is required for pneumatic tools, actuators, or process equipment. The modular connection feature makes it a practical choice for building or expanding FRL (filter-regulator-lubricator) assemblies. Operating temperature range starts at -13 degrees F, making it usable in cold-environment installations such as refrigerated warehouses or outdoor service panels in northern climates.

Key Features

• Handles supply pressures up to 300 psi with a regulated output range of 0 to 125 psi
• Maximum air flow of 233 CFM supports high-demand pneumatic circuits
• 3/4-inch NPT end connections for direct inline installation
• Aluminum die cast body offers durability at a reduced weight
• Built-in relief function releases excess downstream pressure automatically
• Modular connection design integrates with Series 28 filter and lubricator units
• 1/4-inch gauge port allows field installation of a pressure gauge

Compatibility

Designed for use with compressed air systems and compatible with the WILKERSON Series 28 modular FRL product line. Gauge port accepts a standard 1/4-inch NPT gauge fitting.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pipefitter. Depressurize and lock out the air supply line before installing or servicing the regulator. Ensure all NPT threaded connections are properly sealed with thread sealant rated for compressed air service. Do not exceed the 300 psi maximum supply pressure rating.
