Wilkerson R19-02-FA00B Air Regulator 1/4 Npt 300 Psi

Product Description

The WILKERSON R19-02-FA00B is a compressed air regulator designed to control and maintain downstream pressure in pneumatic systems. Built from aluminum die cast, this Series 19 unit handles a maximum supply pressure of 300 psi and delivers up to 64 CFM of airflow through a 1/4 inch NPT port. The regulator includes a built-in relief function, allowing excess downstream pressure to vent when the outlet pressure rises above the set point. It is rated for fluid type compressed air and is intended for installation by industrial maintenance technicians, pneumatic system integrators, and compressed air line service professionals.

The R19-02-FA00B is suited for use in compressed air distribution systems in industrial, commercial, and manufacturing environments. Its modular connection design makes it compatible with Series 19 modular filter-regulator-lubricator (FRL) assemblies, allowing it to be integrated into a multi-component air preparation lineup. The output pressure range is adjustable from 0 to 125 psi, making it appropriate for a broad range of pneumatic tool and equipment applications. A 1/4 inch gauge port thread size is present for optional pressure gauge installation, though no gauge is included with this unit.

Key Features

• Maximum supply pressure of 300 psi for use on high-pressure compressed air lines
• Adjustable outlet pressure range from 0 to 125 psi
• Maximum airflow of 64 CFM through 1/4 inch NPT connections
• Built-in relief function vents excess downstream pressure automatically
• Modular connection design for Series 19 FRL assembly integration
• Aluminum die cast body for durability in industrial service environments
• 1/4 inch gauge port thread size for optional gauge installation

Compatibility

Designed for use with WILKERSON Series 19 modular compressed air preparation systems. Compatible with 1/4 inch NPT compressed air lines handling fluid type compressed air only.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. Depressurize the upstream air supply completely before connecting or disconnecting any components. Follow all applicable local codes and manufacturer guidelines for compressed air system assembly. Do not exceed the rated maximum supply pressure of 300 psi on the inlet port.
