Wilkerson M28-06-CH00B Coalescing Filter 3/4 in Port

Product Description

The WILKERSON M28-06-CH00B is a coalescing filter designed to remove liquid aerosols, oil mist, and fine particulates from compressed air lines. It serves as a critical contamination-control component in pneumatic systems where clean, dry air is required for tools, actuators, and instrumentation. The unit features a 3/4 inch port and includes an integrated sight glass for quick visual inspection of the bowl condition and fluid accumulation level. Licensed HVAC technicians, pipefitters, and industrial maintenance professionals typically install this filter as part of a compressed air treatment train.

This coalescing filter is suited for use in commercial and industrial compressed air distribution systems where oil contamination or moisture carryover would damage downstream equipment. Typical installation points include air preparation stations ahead of pneumatic control valves, spray finishing equipment, and precision air tools. The sight glass allows service personnel to monitor bowl levels without disassembling the unit, reducing maintenance downtime. The 3/4 inch port accommodates mid-range line sizes common in light industrial and commercial facilities.

Key Features

• Coalescing filtration removes liquid aerosols and oil mist from compressed air lines
• 3/4 inch port size fits standard mid-range pneumatic line configurations
• Integrated sight glass allows visual bowl inspection without bowl removal
• Compact footprint at 2.87 inches wide and 9.25 inches tall for tight panel installations
• Replacement-rated construction for direct serviceability in existing filter assemblies

Compatibility

Designed as an OEM-style replacement coalescing filter for compressed air treatment systems with 3/4 inch ported filter housings. Consult the existing filter assembly documentation to confirm bowl and element compatibility before installation.

Installation Notes

Installation should be performed by a qualified pipefitter or pneumatic systems technician. Depressurize and lock out the compressed air supply before removing the existing filter or servicing the bowl. Ensure inlet and outlet flow direction matches the markings on the filter body. Follow applicable facility safety procedures and any local compressed air system codes when integrating into an air preparation circuit.
