Wilkerson M28-06-CG00B Coalescing Filter 3/4 Port

Product Description

The WILKERSON M28-06-CG00B is a coalescing filter designed to remove oil aerosols, fine particulates, and liquid water from compressed air lines. Coalescing filtration works by causing small droplets to merge into larger ones that drain away, producing cleaner downstream air for pneumatic tools, controls, and instrumentation. With a 3/4 inch port, this filter fits mid-range compressed air systems common in light industrial, HVAC mechanical rooms, and trade service environments. Installation and servicing are typically handled by pipefitters, HVAC mechanics, or qualified maintenance technicians working on compressed air distribution systems.

This coalescing filter is suited for compressed air applications where oil carryover or fine aerosol contamination must be controlled before air reaches sensitive downstream equipment. Typical install locations include pneumatic control panels, air-operated HVAC actuators, spray finishing systems, and general shop air lines requiring clean, dry air supply. The 3/4 inch port size positions this unit for moderate-flow branch lines rather than high-volume mains. It is sold and packaged as a single unit.

Key Features

• Coalescing filter element removes oil aerosols and fine liquid particulates from compressed air
• 3/4 inch port size fits standard NPT compressed air line connections
• Compact footprint at 2.87 inches wide and 9.25 inches tall suits tight mechanical installations
• Designed as a serviceable inline filter for ongoing compressed air quality maintenance
• Single-unit packaging supports direct replacement without excess inventory

Compatibility

Designed as an OEM-style replacement coalescing filter for compressed air systems using 3/4 inch ported filter housings in the WILKERSON M28 series product line.

Installation Notes

Depressurize and lock out the compressed air supply before installing or servicing this filter. Installation should follow applicable codes including OSHA 29 CFR 1910.147 lockout/tagout requirements and local compressed air piping standards. Use appropriate thread sealant on NPT connections and verify flow direction markings on the filter body before final assembly. Inspect the drain and element condition periodically as part of a routine compressed air system maintenance schedule.
