Wilkerson M28-06-BK00B Coalescing Filter 3/4 Inch

Product Description

The WILKERSON M28-06-BK00B is a coalescing filter designed to remove oil aerosols, water mist, and fine particulates from compressed air lines. Coalescing filtration works by forcing contaminated airflow through a fiber element that causes small droplets to merge and drain away, protecting downstream equipment from moisture and oil carryover. With a 3/4 inch port size, this filter fits mid-range compressed air systems commonly found in industrial facilities, HVAC mechanical rooms, and pneumatic control applications. Installation and service are typically performed by mechanical contractors, industrial maintenance technicians, or HVAC service professionals who maintain compressed air distribution systems.

This coalescing filter is suited for use in compressed air treatment trains where oil-free or near-oil-free air quality is required. Typical applications include protecting pneumatic actuators, control valves, air-operated HVAC dampers, and instrumentation from liquid contamination. The 3/4 inch port size makes it appropriate for branch or main line installations in light commercial and industrial compressed air systems where flow capacity and clean air quality are equally important.

Key Features

• Coalescing filter element removes oil aerosols and water mist from compressed air streams
• 3/4 inch port size suits mid-range compressed air line installations
• Compact footprint at 2.87 inches wide and 9.25 inches tall for tight mechanical room installs
• Sold individually — single-unit packaging with no minimum order above one unit
• Protects downstream pneumatic equipment, instrumentation, and control components

Compatibility

Designed as an OEM-style replacement coalescing filter for compressed air treatment systems requiring a 3/4 inch ported inline filter stage.

Installation Notes

Installation is performed by qualified mechanical contractors or industrial maintenance technicians familiar with compressed air system service. Always depressurize and isolate the compressed air line before removing or installing any filter body or element. Follow applicable mechanical codes and the system manufacturer guidelines for thread sealant type and installation orientation. Ensure the filter bowl drain is accessible for regular condensate maintenance after installation.
