Wilkerson M08-02-BL00B Coalescing Filter 1/4 Port

Product Description

The WILKERSON M08-02-BL00B is a coalescing filter designed to remove liquid aerosols, oil mist, and fine particulate from compressed air lines. It installs inline at a 1/4 inch port connection and provides a cleaner, drier airstream downstream of the filter stage. Coalescing filters like this one are a standard component in compressed air preparation systems used across HVAC, pneumatic controls, and industrial service applications. The M08-02-BL00B measures 4.71 inches in height and 1.58 inches in width, making it a compact unit suited for tight panel or manifold installations. Typical installers include HVAC technicians and industrial service mechanics working on pneumatic control systems.

This filter is used in compressed air preparation assemblies where oil-free, moisture-reduced air is required to protect downstream components such as regulators, solenoid valves, actuators, and instrumentation. It is appropriate for both light commercial and industrial compressed air systems with 1/4 inch ported connections. The compact form factor allows it to fit into space-constrained installations without requiring extended piping modifications.

Key Features

• Coalescing filter design removes liquid aerosols and oil mist from compressed air
• 1/4 inch port size for standard inline compressed air line connections
• Compact footprint: 4.71 inches tall, 1.58 inches wide
• Lightweight at 0.24 pounds for easy handling and installation
• Single-unit packaging supports individual replacement or system servicing

Compatibility

Designed as an OEM-style replacement coalescing filter for compressed air preparation systems requiring a 1/4 inch port coalescing stage.

Installation Notes

Installation should be performed by a qualified HVAC technician or pneumatic systems mechanic. Depressurize the compressed air line completely before removing the existing filter or making any connections. Follow applicable pneumatic system service procedures and local mechanical codes when installing inline air preparation components. Do not exceed the rated port size or operating pressure limits for this filter assembly.
