Wilkerson L18-02-KL00B Air Lubricator 88 Cfm 1/4 Npt

Product Description

The WILKERSON L18-02-KL00B is a standard compressed air lubricator designed to introduce oil mist into a compressed air stream, protecting downstream pneumatic tools, cylinders, and valves from premature wear. Built around an aluminum die cast body with an aluminum bowl, this Series 18 unit accepts a 1/4 inch NPT port and flows up to 88 CFM. The manual drain and 4 oz bowl keep maintenance straightforward on most shop and production environments. A built-in sight glass allows technicians to confirm oil flow without disassembly. Licensed trades and industrial maintenance personnel are the typical installers.

The L18-02-KL00B suits residential shop compressor systems, light industrial pneumatic circuits, and maintenance-of-way applications where consistent downstream lubrication is required. It is rated for flows to 88 CFM, making it appropriate for circuits serving impact tools, air motors, or small pneumatic actuators operating at typical shop-air pressures. The modular connection feature allows this lubricator to be integrated into a filter-regulator-lubricator (FRL) assembly when paired with compatible Series 18 modular components.

Key Features

• 88 CFM flow capacity handles most light-to-medium industrial pneumatic circuits
• 1/4 inch NPT end connections for straightforward installation into standard compressed air plumbing
• Aluminum die cast body and aluminum bowl for lightweight, corrosion-resistant construction
• Built-in sight glass provides visual confirmation of oil delivery without removing the bowl
• Manual drain on the 4 oz aluminum bowl for simple maintenance
• Modular connection ready for inline FRL assembly with compatible Series 18 components
• Nitrile seals rated down to 14 degrees F (-10 degrees C) for cold-environment service

Compatibility

Designed for use in compressed air systems requiring standard inline lubrication. Modular connection feature supports integration with compatible Wilkerson Series 18 filter and regulator units to form a complete FRL assembly.

Installation Notes

Installation is typically performed by a qualified industrial maintenance technician or plumber familiar with compressed air systems. Depressurize and lock out the compressed air circuit before installing or servicing this lubricator. Use thread sealant rated for compressed air on all NPT connections and torque fittings per the fitting manufacturer's instructions. Verify oil flow through the sight glass after pressurizing the system before returning downstream equipment to service.
