Wilkerson F28-06-SH00B Compressed Air Filter 3/4 in Npt

Product Description

The WILKERSON F28-06-SH00B is a general purpose compressed air filter designed to remove particulates and liquid contaminants from compressed air lines. It uses a sintered polyethylene filter media to capture debris and moisture before they reach downstream equipment. The filter flows up to 145 standard cubic feet per minute (SCFM) through a 3/4 inch NPT port, making it a practical choice for mid-size pneumatic systems. An automatic drain continuously removes accumulated liquid from the 2.87 oz aluminum bowl without manual intervention. A built-in sight glass lets technicians monitor bowl level at a glance. Installed by licensed pipefitters, HVAC technicians, or industrial maintenance professionals wherever clean, dry air is required.

This filter is suited for general industrial and commercial compressed air distribution systems. Its modular connection design allows it to be combined with other Series 28 components, such as regulators and lubricators, to build a full filter-regulator-lubricator (FRL) assembly. Typical applications include protecting pneumatic actuators, air tools, and control instrumentation from particulate contamination and entrained moisture. The 3/4 inch NPT end connections are standard in a wide range of compressor and distribution line configurations found in light manufacturing, mechanical rooms, and shop environments.

Key Features

• 145 SCFM rated flow capacity through 3/4 inch NPT connections
• Sintered polyethylene filter media captures particulates and aerosols
• Automatic drain removes accumulated liquid without manual service
• Sight glass provides visual bowl level monitoring
• Modular Series 28 design supports FRL assembly configurations
• Aluminum bowl with nylon bowl guard for durability and impact resistance

Compatibility

Designed as a modular Series 28 component compatible with other WILKERSON Series 28 filter, regulator, and lubricator units for inline compressed air system assembly.

Installation Notes

Installation should be performed by a qualified pipefitter or maintenance technician. Depressurize and lock out the compressed air system fully before installing or servicing this filter. Ensure NPT threads are properly sealed with thread tape or pipe sealant rated for compressed air service and tighten to a snug fit without overtorquing. Mount the unit vertically with the bowl facing downward to allow the automatic drain to function correctly.
