Wilkerson F28-06-SG00B Compressed Air Filter 3/4 in Npt

Product Description

The WILKERSON F28-06-SG00B is a general purpose compressed air filter designed to remove liquid water, particulate, and contaminants from compressed air lines in industrial and commercial pneumatic systems. Built on the Series 28 platform, it accepts a 3/4 in NPT connection and delivers a rated flow of 145 standard cubic feet per minute (SCFM). The sintered polyethylene filter media captures particulate and coalesces moisture efficiently. An automatic drain removes collected liquid without manual intervention, reducing maintenance overhead in continuous-duty installations. A polycarbonate bowl with a nylon bowl guard gives a clear view of bowl contents while providing mechanical protection. Licensed technicians and pipefitters typically handle installation in compressed air distribution systems.

The F28-06-SG00B is suited for point-of-use and branch-line filtration in manufacturing, maintenance, and production environments where clean, dry air is required for pneumatic tools, actuators, and control equipment. The modular connection feature allows the unit to be combined with other Series 28 components such as regulators and lubricators to build a filter-regulator-lubricator (FRL) assembly without additional hardware. The built-in sight glass allows quick visual inspection of the bowl level without removing the unit from service.

Key Features

• 145 SCFM rated flow capacity through a 3/4 in NPT port
• Sintered polyethylene filter media removes particulate and coalesces liquid water
• Automatic drain expels collected liquid continuously without manual intervention
• Polycarbonate bowl with nylon bowl guard provides visual inspection and impact protection
• Integrated sight glass for quick bowl-level monitoring during operation
• Modular connection compatible with Series 28 regulators and lubricators for FRL assembly

Compatibility

Designed as an OEM-style replacement and new-installation filter for compressed air systems requiring a 3/4 in NPT port connection and Series 28 modular FRL components.

Installation Notes

Installation should be performed by a qualified pipefitter or pneumatic systems technician. Depressurize and lock out the compressed air supply before mounting or servicing the filter. Apply appropriate thread sealant to NPT connections per shop practice and applicable codes. Do not exceed the rated pressure or temperature limits of the polycarbonate bowl when selecting installation location.
