Wilkerson D28-06-FLG0B Frl Unit 3/4 Npt 150 Scfm

Product Description

The WILKERSON D28-06-FLG0B is a 2-piece filter/regulator/lubricator (FRL) combination unit designed for compressed air system conditioning in industrial and commercial pneumatic applications. It integrates filtration, pressure regulation, and lubrication into a single inline assembly, delivering up to 150 SCFM at a maximum supply pressure of 250 psi. The unit features aluminum body and bowl construction, a 5-micron filter element, and a manual drain. A pressure gauge and sight glass are included. Licensed HVAC technicians, industrial maintenance mechanics, and fluid power specialists install this type of unit upstream of pneumatic tools, actuators, and control valves.

This FRL unit is suited for industrial plant air systems, pneumatic automation lines, and compressed air distribution networks requiring continuous air preparation. The 3/4 NPT port size accommodates medium-to-high flow branch lines. Its modular connection design allows integration into multi-unit FRL assemblies within WILKERSON Series 28 configurations. The manual drain requires periodic attention during service intervals. Mounting brackets are included, supporting direct panel or pipe installation. Typical operating temperature range is -13 degrees F to 150 degrees F, making it appropriate for most indoor and light-duty outdoor compressed air environments.

Key Features

• 2-piece filter/regulator/lubricator combination in a single modular assembly
• 150 SCFM flow capacity with 250 psi maximum supply pressure rating
• 5-micron filtration with aluminum bowl and manual drain
• Includes pressure gauge, sight glass, and mounting brackets
• Modular connection supports multi-unit Series 28 assemblies
• Operating range of -13 degrees F to 150 degrees F

Compatibility

Designed as an OEM-style component within the WILKERSON Series 28 modular FRL system, compatible with other Series 28 modular units via the integrated modular connection port.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or fluid power specialist. Depressurize and lock out the compressed air supply completely before installing or servicing this unit. Ensure port connections are sealed with appropriate thread sealant per applicable plumbing and pneumatic system codes. Do not exceed the rated maximum supply pressure of 250 psi during operation or testing.
