Wilkerson D28-06-FKG0B Frl Unit 3/4 Npt 150 Scfm

Product Description

The WILKERSON D28-06-FKG0B is a 2-piece FRL combination unit integrating a filter, regulator, and lubricator into a single modular assembly for compressed air systems. Rated at 150 SCFM with a maximum supply pressure of 150 psi, it handles the flow demands of most industrial and commercial pneumatic tool lines. The unit features a 5-micron filtration rating to remove particulate from the air supply, a manual drain on the filter bowl, and an included pressure gauge for inline monitoring. A licensed pneumatic or industrial maintenance technician typically installs and services this type of assembly.

This FRL unit is suited for industrial, commercial, and heavy-duty shop compressed air distribution lines using 3/4 NPT connections. The modular design allows it to be integrated into an existing Series 28 lineup or installed as a standalone assembly. Its operating temperature range of -13 degrees F to 125 degrees F covers most indoor plant and shop environments. The included mounting brackets simplify installation on standard air supply drops or panel-mount configurations.

Key Features

• 150 SCFM flow capacity at 3/4 NPT port size for high-demand pneumatic systems
• Maximum supply pressure of 150 psi
• 5-micron filter element removes fine particulate from compressed air supply
• Polycarbonate filter and lubricator bowls with bowl guards for safe level monitoring
• Manual drain on filter bowl for controlled condensate removal
• Modular connection supports integration with other Series 28 components
• Pressure gauge and mounting brackets included

Compatibility

Designed for use with Series 28 modular compressed air treatment systems using 3/4 NPT end connections. Consult the manufacturer documentation to confirm fitment with existing Series 28 filter, regulator, and lubricator assemblies before ordering.

Installation Notes

Installation and servicing should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize and lock out the compressed air supply line completely before installing or servicing this unit. Verify that upstream supply pressure does not exceed the 150 psi rating of the unit. Follow applicable facility safety procedures and local compressed air system codes when integrating this assembly into an existing air distribution system.
