Wilkerson D18-02-FKG0B Frl Unit 1/4 Npt 45 Scfm 150 Psi

Product Description

The WILKERSON D18-02-FKG0B is a compact 2-piece FRL combination unit that integrates a filter, regulator, and lubricator into a single inline assembly for compressed air systems. Rated at 45 SCFM with a maximum supply pressure of 150 psi, it conditions compressed air by removing particulates down to 5 microns, regulating line pressure, and delivering metered lubrication to downstream pneumatic tools and equipment. The aluminum body and polycarbonate bowl with bowl guard keep the assembly lightweight and durable. A pressure gauge and manual drain are included. Licensed HVAC technicians, pipefitters, and industrial maintenance professionals install this type of unit in pneumatic supply lines.

The D18-02-FKG0B is suited for light industrial, commercial, and production environments where consistent, clean, and lubricated air supply is required at 1/4 NPT connection points. The compact Series 18 body keeps the footprint small for installations where panel or cabinet space is limited. The modular connection design allows the unit to be configured or expanded within a compatible FRL system. Mounting brackets are included, simplifying panel or wall installation. The unit is rated for operating temperatures from -13 degrees F to 125 degrees F.

Key Features

• 2-piece filter/regulator-lubricator configuration in a compact Series 18 body
• 45 SCFM flow capacity with 150 psi maximum supply pressure
• 5-micron filtration rating for downstream component protection
• Manual drain and polycarbonate bowl with bowl guard for easy visual monitoring and maintenance
• Pressure gauge included with 1/4 NPT gauge port
• Modular connection design with mounting brackets included

Compatibility

Designed as an OEM-style FRL combination unit for compressed air supply lines using 1/4 NPT end connections in industrial, commercial, or production pneumatic systems.

Installation Notes

Installation is typically performed by a licensed pipefitter or qualified maintenance technician. Depressurize and lock out the compressed air supply line before installing or servicing this unit. Ensure flow direction arrows on the body align with the direction of air travel in the line. Follow applicable OSHA and local compressed air safety codes when working on pressurized systems.
