Wilkerson C18-02-FLG0B Frl Unit 1/4 Npt 42 Scfm

Product Description

The WILKERSON C18-02-FLG0B is a compact, 3-piece Filter-Regulator-Lubricator (FRL) combination unit designed for compressed air system conditioning in pneumatic applications. It filters particulates down to 5 microns, regulates downstream pressure, and lubricates air-operated equipment in a single inline assembly. With a maximum supply pressure of 250 psi and a flow capacity of 42 SCFM, this unit handles the demands of most industrial and commercial pneumatic circuits. The aluminum body and bowl construction keeps weight manageable while providing durability in shop and production environments. A 1/4 NPT port size suits smaller-bore pneumatic lines. Licensed HVAC, mechanical, and industrial maintenance technicians install this type of unit as part of air preparation on compressor-fed tool and control systems.

The C18-02-FLG0B is suited for light to medium industrial pneumatic systems where clean, regulated, and lubricated air is required at point of use. The compact Series 18 body format fits installations where panel or manifold space is limited. The unit includes a pressure gauge, sight glass for lubricator oil level monitoring, brackets for mounting, and a manual drain on the filter bowl. It is appropriate for production lines, maintenance shops, and equipment rooms where compressed air quality directly affects tool life and pneumatic actuator performance. Operating temperature range is -13 degrees F to 150 degrees F.

Key Features

• 3-piece FRL combination: filter, regulator, and lubricator in one modular assembly
• 5-micron filtration rating removes particulates from compressed air supply
• 250 psi maximum supply pressure with 42 SCFM flow capacity
• Aluminum body and bowl construction for lightweight, corrosion-resistant service
• Includes pressure gauge, sight glass, and mounting brackets
• Manual drain on filter bowl; modular connection allows system expansion
• Filter bowl capacity 1.7 oz; lubricator bowl capacity 4.0 oz

Compatibility

Designed as an OEM-style compressed air preparation unit for pneumatic systems using 1/4 NPT connections. Fits inline on compressed air supply lines serving pneumatic tools, actuators, and control valves where filtration, regulation, and lubrication are required at a single service point.

Installation Notes

Installation is performed by licensed mechanical or industrial maintenance technicians familiar with compressed air systems. Depressurize and lock out the compressed air supply completely before installing or servicing this unit. Ensure flow direction arrow on the body aligns with system air flow direction. Follow applicable OSHA and ANSI compressed air safety standards when setting operating pressure after installation.
