Wilkerson B28-04-FK00 Filter/Regulator 150 PSI 11.44 Inches Height 2.90 Inches Width

Product Description

The Wilkerson B28-04-FK00 Filter/Regulator is designed for efficient air filtration and pressure regulation. This model is suitable for various pneumatic applications and ensures optimal performance.

• Rated at 5 microns
• Maximum flow of 165 CFM
• 1/2 inch NPT pipe size

Product Highlights

This filter/regulator features a polycarbonate bowl with guard, offering durability and protection. The non-rising adjustment knob provides ease of use, and it comes with a 1/4 inch gauge port.

Product Information

Standard Information

• Brand: Wilkerson
• MPN: B28-04-FK00

Technical Specifications

• Pipe Size: 1/2 inch NPT
• Max Flow: 165 CFM
• Max Pressure: 150 PSI
• Max Temperature: 125 Degrees Fahrenheit
• Filter Rating: 5 micron
• Bowl Material: Polycarbonate with Guard
• Bowl Size: 6.1 ounces
• Adjustment Range: 0 to 125 PSI
• Gauge Port Size: 1/4 inch
• Overall Height: 11.44 inches
• Overall Width: 2.90 inches
