WIKA 2.5-1000 Pressure Gauge

Product Description

The WIKA 213.53-1000 is a pressure gauge made for industrial use. It has a two point five inch dial and a durable 304 stainless steel case. This gauge measures pressure from zero to one thousand psi. It features copper alloy wetted parts and a polycarbonate lens for visibility. The liquid-filled gauge uses glycerin to perform well in high vibration settings. It is built to meet ASME Grade A standards.

• Dial Size: 2.5 inches
• Case Material: 304 Stainless Steel
• Pressure Range: 0 to 1000 psi

Product Highlights

The pressure gauge is suitable for various industrial applications and offers reliable performance in challenging conditions.

Product Information

Standard Information

• Manufacturer: WIKA
• Series: 213.53

Technical Specifications

• Model: 213.53
• Case Type: Plain
• Primary Range: 0-1000 psi
• Connection Location: Bottom
• Connection Size: 1/4 NPT
• Lens Type: Polycarbonate
• Dry or Filled: Glycerin
• Wetted Parts: Copper
• Mounting: 1/4 NPTM Bottom Stem
• Accuracy: ±2-1-2%
• Dial Material: White ABS Plastic
• Bourdon Tube Material: Stainless Steel
• Movement and Pressure Connection Material: Copper Alloy
• Window Material: Polycarbonate
• Gasket Material: Buna-N
• Pointer Material: Black Aluminum
