Wieland 81.020.0011.0 Time Twin-1 24-240V AC/DC (22.5 mm) 8102000110

Product Description

The Wieland 81.020.0011.0 Time Twin-1 is a multi-range repeat cycle time delay relay offering eight selectable time ranges from 0.1 seconds to 100 hours with independently adjustable pulse and pause durations and selectable pulse-or-pause start. It accepts 20.4 to 264 V AC/DC (rated 24-240 V AC/DC), consumes 4.5 VA at 240 V AC or 1.1 W at 24 V DC, and provides one SPDT changeover contact rated 5 A. The unit mounts on a 22.5 mm DIN rail for control cabinet and automation applications.

• Multi-range repeat cycle relay with eight selectable time ranges (0.1 s to 100 h); separate pulse and pause adjustment and pulse-or-pause start
• Wide supply range 20.4 to 264 V AC/DC (rated 24-240 V AC/DC); power consumption 4.5 VA @240 V AC / 1.1 W @24 V DC
• One SPDT (1 Form C) changeover contact, 5 A switching, AgNi contact material, 100,000 mechanical operations; DIN-rail mount, screw terminals, 22.5 mm width

Product Highlights

Multi-range repeat cycle time delay relay; 0.1 s to 100 h; 20.4–264 V AC/DC input; 1 SPDT 5 A AgNi contact; 22.5 mm DIN-rail housing.

Product Information

Standard Information

• Brand: WIELAND
• Manufacturer Part Number: 8102000110
• Country of Origin: CN

Technical Specifications

• Brand: Wieland
• Manufacturer Part Number: 81.020.0011.0
• Alternate MPN: 8102000110
• Product Name: Time Twin-1
• Function: Multi-range repeat cycle time delay relay
• Input Voltage: 20.4 to 264 V AC/DC
• Rated Supply Voltage: 24-240 V AC/DC
• Supply Range: 20.4 to 264 V AC/DC
• Time Range: 0.1 s to 100 h
• Selectable Time Ranges: Eight
• Contact Configuration: SPDT (single pole double throw)
• Contact Form: 1 Form C
• Maximum Current Rating: 5 A
• Contact Rating: 5 A at 250 V AC; 5 A at 24 V DC
• Contact Material: AgNi
• Maximum Switching Voltage: 250 V AC; 30 V DC
• Power Consumption: 4.5 VA at 240 V AC; 1.1 W at 24 V DC
• Mechanical Life: 100,000 operations
• Mounting Type: DIN rail
• Mounting Width: 22.5 mm
• Termination Style: Screw terminal
• Dimensions (mm): 89.4 x 22.5 x 100
• Weight: 0.12966 kg
• RoHS: Yes
• Country of Origin: CN
• Contact Terminals: Fixed screw terminals
