Wiegmann SC121804NK N1 Screw Cover (12 x 18 x 4)

Brand: WIEGMANN
SKU: SC121804NK
Availability: Out Of Stock
$70.12
$70.12
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Wiegmann SC121804NK is an N1 screw-cover enclosure fabricated from 16-gauge carbon steel for use as a junction box and pull box. Nominal size 12 x 18 x 4 in (actual 12.125 x 18.125 x 4.188 in) provides 864 cubic inches of capacity. The spot-welded enclosure features a flat removable screw cover fastened with plated steel screws, embossed rear mounting holes, NEMA 1 rating, and UL/CSA (cULus) listings.

  • Material: 16-gauge carbon steel construction with ANSI-61 gray textured finish; spot welded
  • Dimensions: Nominal 12 x 18 x 4 in (HxWxD); Actual 18.125 in x 12.125 in x 4.188 in; (note: actual volume based on these dimensions is �920.4 cu.in)
  • Features: Flat removable screw cover fastened with plated steel screws, no knockouts, embossed rear mounting holes, NEMA 1, UL/CSA listed

Product Highlights

12 x 18 x 4 in NEMA 1 screw-cover enclosure, 16-gauge carbon steel, no knockouts

Product Information

Standard Information

  • Brand: WIEGMANN
  • Manufacturer Part Number: SC121804NK
  • Country of Origin: United States
Technical Specifications
Brand
Wiegmann
Manufacturer Part Number
SC121804NK
Series
SC Series
Type
Enclosure (N1 screw-cover / pull box)
Material
Carbon steel (16 gauge)
Construction
Spot welded
Cover Type
Flat removable screw cover, fastened with plated steel screws
Knockouts
None (No knockouts)
NEMA Rating
1
Cubic Capacity
�920.4 cu.in (based on actual dimensions 18.125 x 12.125 x 4.188 in)
Nominal Dimensions (H x W x D)
12 in x 18 in x 4 in
Actual Dimensions (L x W x H)
18.125 in x 12.125 in x 4.188 in
Weight
12.8 lb
Mounting Type
Wall mount / Embossed rear mounting holes
Finish
ANSI-61 gray textured finish; polyester powder coat over phosphatized surface
Application
Junction box and pull box for commercial and general industrial applications
Listings / Certifications
UL, CSA, cULus; UL File No. E23553; CSA File No. LL66078
Compliance
RoHS indicator; ARRA / Buy American Act compliant
Country of Origin
United States
