Wiegmann HS666 Straight Wireway NEMA 1 6 Ft

Product Description

The WIEGMANN HS666 straight wireway is designed to protect electrical wiring in environments where dirt, dust, oil, and water are not serious concerns. It features a NEMA 1 enclosure and a combination hinge/screw cover for easy access. The wireway is constructed from 16 gauge steel and has knockouts on the side walls.

• NEMA 1 enclosure rating
• Constructed from 16 gauge steel
• Hinged cover with screw locking style

Product Highlights

This straight section wireway is ideal for protecting electrical wiring in dry, indoor environments. It offers convenient access with its hinged cover and lay-in design.

Product Information

Standard Information

• Brand: WIEGMANN
• Manufacturer Part Number: HS666
• Country of Origin: US

Technical Specifications

• Nema Enclosure Type: 1
• Width: 6 In
• Height: 6 In
• Length: 72 In
• Knockouts: With Knockouts
• Gauge Steel: 16 Gauge Steel
• Finish: Ansi 61 Gray Polyester Powder Finish
• Certifications: Ul Listed And Csa Certified
• Material: 16 gauge carbon steel
• Standard: cULus
• Type: Wireway
• Gauge: 16 ga
• Finish Type: Polyester Powder
• Listings: UL, CSA
• Enclosure: Nema 1 Type Enclosure
• Standards: CSA Certified, UL Listed
• UL Listed: Yes
• Cover Type: Hinged Cover
• Application: Designed to protect electrical wiring in applications where dirt, dust, oil, and water are not serious problems. All sections are open on one side so wires and cable can be laid in along an entire wireway run.
• NEMA Rating: NEMA 1
• Basic Finish: Powder Coated
• Wireway Width: 6 in
• Wireway Height: 6 in
• With Knockouts: Yes
• Certified Listed: cULus
• Cover Type - Broad: Hinged Cover
• Cover Locking Style: Screw
• NEMA Rating - Broad: 1
• NEMA Enclosure Rating: 1
• With/Without Knockouts: Yes
• Length (Straight Wireway): 72 in
• Country of Origin (subject to change): United States
• Catalog Number: HS666
• EU RoHS Indicator: Yes
• Series: HS Series
• Country of origin: US
• Nominal Length: 72 "
• Nominal Height: 6 "
• Nominal Width: 6 "
• Net Weight: 33 lbs
• Gross Weight: 33 lbs
• Brand: Wiegmann
• MPN: HS666
