WHITE-RODGERS WR-1F80-0261 Programmable Thermostat

Product Description

The WHITE-RODGERS WR-1F80-0261 is a programmable thermostat suitable for single-stage heating and cooling systems, including heat pump applications. This thermostat offers various scheduling options including 5/1/1 day, 24-hour, or non-programmable settings.

• Compatible with multiple system types: gas, oil, electric, and millivolt.
• Features a lighted display for easier reading in low-light areas.
• Installation uses push-connect, color-coded terminals for convenience.

Product Highlights

This thermostat helps manage energy consumption while providing flexibility in programming schedules. It includes a low battery indicator and an option for filter change reminders to help maintain optimal home conditions.

Product Information

Standard Information

• Brand: WHITE-RODGERS
• Power Method: Battery, Hardwire

Technical Specifications

• Temperature Range: 45°F to 90°F (7.22°C to 32.22°C)
• Dimensions: 4.8 inches wide x 1.5 inches deep x 3.8 inches high
• Voltage Rating: 24 VAC and battery options
• Compatible Systems: Heat Pump, Gas, Oil, Electric, Millivolt
• Terminal Designations: R,C,W,Y,O/B,G
• Batteries Included: Yes
• Weight: 0.65 lbs
