White-rodgers 90 295QS1 General Purpose Relay 8A

Product Description

The WHITE-RODGERS 90 295QS1 is a general purpose relay rated at 8 amps, designed for switching and control applications in HVAC and light commercial systems. Relays of this type serve as the electrical switching interface between low-voltage control circuits and line-voltage loads, allowing thermostats, control boards, and other signal devices to energize fans, compressors, pumps, or auxiliary equipment. The 90 295QS1 is a compact, single-unit component suited for panel or enclosure mounting. HVAC technicians and controls electricians install this relay as part of new control systems or as a direct replacement in existing equipment.

This relay is appropriate for residential and light commercial HVAC applications where an 8A-rated switching relay is required. Typical install scenarios include air handler control panels, rooftop unit accessories, and custom control panel builds. It is also used in ancillary applications such as pump control, damper actuator circuits, and zone control wiring where a general purpose relay fits the amperage and switching requirements of the circuit.

Key Features

• 8A rated switching capacity for general purpose control applications
• Compact single-unit form factor suitable for panel and enclosure mounting
• Designed for use in low-voltage and line-voltage switching circuits
• Lightweight construction at 0.2 pounds for easy handling and installation

Compatibility

Designed as an OEM-style general purpose relay for residential and light commercial HVAC control panel applications requiring an 8A switching relay.

Installation Notes

Installation should be performed by a licensed HVAC technician or electrician. De-energize the circuit and verify zero voltage at the relay terminals before handling or wiring. Follow applicable NEC requirements for control circuit wiring and enclosure ratings. Confirm that the load amperage does not exceed the 8A relay rating before energizing the circuit.
