White-Rodgers 3L05-6 Snap Disc Limit Control

Product Description

The White-Rodgers 3L05-6 is a snap disc limit control designed specifically for heating systems. This control manages temperature efficiently due to its adjustable set point, which ranges from two hundred ten to two hundred fifty degrees Fahrenheit. It features a single pole single throw (SPST) switch that opens when the temperature rises. The device includes one-quarter inch quick connect terminals for easy installation and connection.

• Adjustable set point between two hundred ten to two hundred fifty degrees Fahrenheit
• SPST switch functionality that opens on rise
• One-quarter inch quick connect terminals for straightforward installation

Product Highlights

This control is essential for maintaining correct temperature settings in heating applications.

Product Information

Standard Information

• Brand: White-Rodgers
• MPN: 3L05-6

Technical Specifications

• Type: Snap Disc Limit Control, Adjustable Set Point
• Mounting Type: Flanged Airstream Mount
• Switch Type: SPST, Opens on Rise
• Terminal Type: 1/4 Inch Quick Connect
• Input Voltage: 120/240 Volt AC
• Full Load Current Rating: 14 Amp at 120 Volt AC, 10 Amp at 240 Volt AC
• Locked Rotor Current Rating: 72 Amp at 120 Volt AC, 60 Amp at 240 Volt AC
• Resistive Current Rating: 25 Amp at 120/240 Volt AC
• Power Rating: 125 Volt Amp at 120/240 Volt AC (Pilot Duty)
• Temperature Rating: 210 to 250 Degrees Fahrenheit
• Differential Temperature Rating: 40 Degrees Fahrenheit
