White-Rodgers 3F01-110 Snap Disc Fan Control 110F Replaces 3F01-111 60T12-610044

Product Description

The White-Rodgers 3F01-110 Snap Disc Fan Control is a reliable device for regulating the operation of fans in HVAC systems. This snap disc fan control is designed to provide precise temperature control, improving ventilation efficiency.

• 110 degrees F cut-in, 90 degrees F cut-out
• Close on rise switch action
• Compact and straightforward to install

Product Highlights

This snap disc fan control is ideal for HVAC systems, industrial fans, and ventilation ducts. It ensures efficient airflow and energy management.

Product Information

Standard Information

• Brand: White-Rodgers
• Model: 3F01-110

Technical Specifications

• Switch Action: Close on rise
• Temperature Rating: 110 degrees F cut-in, 90 degrees F cut-out
• Resistive Rating: 21.6 A at 277 VAC, 25 A at 120/240 VAC
• Pilot Duty Rating: 125 VA at 120/240/277 VAC
• Dimensions: 2.44 x 2.44 x 1.22 inches
• Weight: 0.22 pounds
• Type: Snap Disc
• Country of Origin: CH
