White-Rodgers 2A37-1 Line Voltage SPST Open Thermostat 20-90°F

Product Description

The White-Rodgers 2A37-1 line voltage SPST thermostat is designed to control heating systems in commercial and industrial settings. This thermostat operates on a wide temperature range of 20 to 90 degrees Fahrenheit with an adjustable differential of 3 to 20 degrees Fahrenheit.

• Compatible with 120-240 VAC systems
• Features a coiled bulb sensor for accurate temperature sensing
• Durable construction suited for industrial use

Product Highlights

This White-Rodgers thermostat is ideal for use in garages, factories, and warehouses. Its single-pole, single-throw design makes it effective for various heating applications.

Product Information

Standard Information

• Brand: White-Rodgers
• Model: 2A37-1
• Category: HVAC Supplies

Technical Specifications

• Temperature Range: 20 to 90 degrees Fahrenheit
• Adjustable Differential: 3 to 20 degrees Fahrenheit
• Voltage Compatibility: 120-240 VAC
• Sensor Type: Coiled bulb
• Switch Action: Open on rise
• Contact Ratings: 14.0 A AFL (120V), 7.0 A AFL (240V)
• Weight: 1.64 lbs
• Dimensions: 5.375 inches (Height), 2-9/16 inches (Depth), 2-5/16 inches (Width)
