Whirlpool W11560536 Coil Assembly Heat Exchanger

Product Description

The WHIRLPOOL W11560536 is a coil assembly designed for use in Whirlpool home appliance systems requiring heat exchange at a 180-degree configuration. This small-format flow heat exchanger coil serves as an OEM-replacement component, restoring proper thermal transfer performance in the systems it supports. Installation is typically performed by a qualified appliance or HVAC technician. The part number W11560536 identifies this assembly within the Whirlpool parts catalog and is sourced directly as an OEM-spec component.

This coil assembly is intended for residential Whirlpool appliance applications where a compact heat exchanger coil is required. The 180-degree coil orientation and small-format sizing indicate fitment in space-constrained appliance configurations. This part is suited for service technicians handling appliance repairs requiring coil replacement to restore heating or thermal regulation function.

Key Features

• 180-degree coil configuration for compact appliance installations
• Small-format design suited for space-constrained system compartments
• OEM Whirlpool replacement part for accurate fit and function
• Restores proper heat exchange performance upon installation

Compatibility

Designed as an OEM-style replacement coil assembly for Whirlpool residential appliances requiring a small-format 180-degree flow heat exchanger component.

Installation Notes

Installation should be performed by a qualified appliance service technician. Disconnect power to the appliance before beginning any service work. Handle the coil assembly carefully to avoid deforming the tubing or fins, as physical damage can reduce heat transfer efficiency. Follow the appliance service manual for proper mounting and connection procedures.

Technical Specifications

• Coil Configuration: 180 degrees
• Format: Small

Standard Information

• Brand: WHIRLPOOL
• Manufacturer Part Number: W11560536
