Whirlpool W11378584 Orifice Holder Assembly

Product Description

The WHIRLPOOL W11378584 is an OEM replacement orifice holder assembly designed to restore proper gas flow regulation in Whirlpool appliances. The orifice holder secures the burner orifice in precise alignment, ensuring consistent fuel delivery to the burner assembly. This part addresses failure from heat cycling, corrosion, or physical damage that can disrupt orifice seating and affect combustion performance. Installation is handled by licensed appliance technicians or qualified HVAC-gas professionals as part of burner assembly service or gas valve component replacement.

This orifice holder assembly is suited for residential appliance applications where the original part has worn, cracked, or become misaligned. It is used during routine burner maintenance or as part of a broader gas train repair. Replacing the holder restores correct orifice positioning, which directly affects flame characteristics and appliance efficiency. This part is appropriate for service calls involving incomplete combustion, burner ignition issues, or gas component overhaul.

Key Features

• OEM replacement part manufactured to original factory specifications
• Secures burner orifice in precise alignment for consistent gas flow
• Designed to withstand repeated heat cycling in residential appliance environments
• Direct-fit replacement reduces installation time and alignment adjustment

Compatibility

Designed as an OEM-style replacement orifice holder assembly for Whirlpool residential appliances. Refer to your appliance model number and parts diagram to confirm fitment before installation.

Installation Notes

This part should be installed by a licensed appliance repair technician or qualified gas service professional. Shut off the gas supply at the appliance shutoff valve and disconnect power before beginning any disassembly. Follow all applicable local gas codes and manufacturer service documentation during installation. Do not operate the appliance until all gas connections have been leak-tested with an approved solution.

Technical Specifications

• Part Type: Orifice Holder Assembly

Standard Information

• Brand: WHIRLPOOL
• Manufacturer Part Number: W11378584
