Whirlpool W10185982 Dryer Timer Control Electric (Replaces AP6016541 PS11749831 24066166)

Product Description

Whirlpool W10185982 is a dryer timer control designed to manage dryer cycles and timing functions for compatible Whirlpool and related brand dryers. The assembly features a D-shaped shaft, multiple external terminals for wiring, and is intended as a direct replacement for listed part numbers. It is an electric timer suitable for dryer repair and maintenance tasks where original timer functionality is required.

• Terminal configuration: 10 x 1/4-inch male terminals (A, B, C, H, X, T, F, W, S, T2), 2 x 1/8-inch motor terminals, plus 1 x 1/4-inch terminal on mounting bracket
• Mechanical interface: D-shaped shaft for correct knob mounting and alignment
• Compatibility and replacements: Compatible with select Whirlpool, Amana, Jenn Air, Kenmore, Magic Chef, Maytag, and KitchenAid dryers; replaces AP6016541, PS11749831, 24066166

Product Highlights

Electric dryer timer control assembly with D-shaped shaft and multi-terminal wiring for direct replacement of specified Whirlpool and compatible part numbers.

Product Information

Standard Information

• Brand: WHIRLPOOL
• Manufacturer Part Number: W10185982

Technical Specifications

• Brand: Whirlpool
• Manufacturer Part Number: W10185982
• Alternate Part Numbers: WPW10185982, AP6016541, PS11749831, 24066166
• Replaces / Production Numbers: AP6016541; PS11749831; 24066166; 418-618-20-B5; 418-613-20-B5; W10185982 E
• Product Type: Dryer timer control
• Power Source: Electric
• Terminal Configuration: 10 x 1/4-inch male terminals (marked A,B,C,H,X,T,F,W,S,T2); 2 x 1/8-inch male motor terminals; 1 x 1/4-inch terminal on metal mounting bracket
• Shaft Type: D-shaped
• Item Height: 3.63 in
• Included Components: Dryer timer control
• Compatible Brands: Whirlpool, Amana, Jenn Air, Kenmore, Magic Chef, Maytag, KitchenAid
• Category: Washer & dryer parts / Dryer parts
