Whirlpool 69029109289 Coupling 2 Inch Sw A105

Product Description

The WHIRLPOOL 69029109289 is a 2-inch forged steel socket weld coupling rated for high-pressure piping service. Built to ASTM A105 material standards, this fitting is designed for use in pressure piping systems where a reliable, permanent pipe connection is required. The socket weld end configuration allows the pipe to be inserted into the fitting socket before welding, producing a strong, leak-resistant joint. Licensed pipefitters and mechanical contractors install this type of fitting in industrial and commercial piping systems where system integrity under pressure is critical.

This coupling is suited for use in high-pressure piping assemblies operating under demanding service conditions. The 6000-pound pressure class rating makes it appropriate for high-pressure socket weld applications in industrial process, utility, and mechanical systems. It is typically installed in locations requiring a straight inline pipe connection between two pipe segments of equal diameter.

Key Features

• 2-inch nominal pipe size for straightforward inline connection
• Socket weld end configuration for welded, leak-resistant joints
• 6000-pound pressure class rating for high-pressure service
• ASTM A105 forged carbon steel construction for strength and durability
• Designed for permanent, full-penetration welded installations

Compatibility

Designed as an OEM-style replacement or direct-use fitting for 2-inch socket weld piping systems operating within the 6000-pound pressure class.

Installation Notes

Installation must be performed by a qualified pipefitter or welder in accordance with applicable mechanical and pressure piping codes, including ASME B31.1 or B31.3 as applicable to the system. Isolate and fully depressurize the piping system and allow it to cool before cutting in or replacing any fitting. Socket weld fittings require a small gap between the pipe end and the socket bottom before welding to allow for thermal expansion during the weld cycle. Do not substitute socket weld fittings for threaded or slip-on configurations without engineering review.
