Westlake Pipe & Fittings 854-015 1-1/2 in PVC Van Stone Flange (1-1/2 in)

Product Description

Westlake Pipe & Fittings 854-015 is a 1-1/2 in PVC Van Stone flange for 1-1/2 in piping systems. The loose-ring slip-on style flange is molded from rigid PVC to ASTM D-1784 for use in Schedule 80/XH systems. It includes four bolt holes (1/2 in), a pressure class of 150 lb (150 psi), and is intended for sealed flanged connections using recommended elastomeric gaskets.

• Rigid PVC construction conforming to ASTM D-1784; Schedule 80/XH rating
• Loose-ring slip-on Van Stone flange for 1-1/2 in nominal pipe with 4 bolt holes (1/2 in)
• Pressure class 150 lb (150 psi); recommended full-face 1/8 in elastomeric gaskets

Product Highlights

1-1/2 in PVC loose-ring Van Stone flange; 4 bolt holes; 150 lb/150 psi; ASTM D-1784

Product Information

Standard Information

• Brand: WESTLAKE PIPE & FITTINGS
• Manufacturer Part Number: 854-015
• Country of Origin: US

Technical Specifications

• Brand: WESTLAKE PIPE & FITTINGS
• MPN: 854-015
• Manufacturer Part Number: 854-015
• Product Name: 1-1/2 in PVC Van Stone Flange
• Product Type: Loose ring / Slip-on Van Stone flange
• Material: Rigid PVC (ASTM D-1784)
• Nominal Size: 1-1/2 in
• Number of Bolt Holes: 4
• Bolt Hole Size: 1/2 in
• Bolt Size: 1/2-13 UNC x 2-3/4 in L
• Pressure Class: 150 lb
• Pressure Rating: 150 psi
• Schedule Rating: SCH 80/XH
• Standards/Approvals: ASTM D-1784
• Weight: 0.549 lb
• Dimensions (L x W x H): 1.5 x 5.0 x 5.0 in
• Country of Origin: US
