Westlake Pipe Fittings 7060701 3-way Ball Valve 1-1/2 in Brass

Product Description

The WESTLAKE PIPE FITTINGS 7060701 is a 1-1/2 inches threaded brass 3-way ball valve designed for fluid control applications requiring flow diversion or mixing in a single fitting. The full-port, three-way configuration allows the operator to direct flow between multiple lines without additional fittings or complex manifold assemblies. Constructed from brass, this valve offers solid corrosion resistance in both potable water and general-purpose plumbing applications. At 5.22 pounds, it carries the mass consistent with heavy-wall commercial-grade construction. Licensed plumbers and pipefitters are the typical installers for this type of valve in commercial and residential plumbing systems.

This valve is suited for residential and light commercial plumbing installations where a single shutoff or diversion point is needed between two or more supply or return lines. Common applications include hydronic heating distribution, domestic water systems, irrigation manifolds, and process piping where flow direction must be controlled at a single service point. The threaded end connections allow direct installation into standard NPT-threaded pipe runs without special tooling or adapters.

Key Features

• 3-way ball valve design enables flow diversion or mixing at a single service point
• 1-1/2 inches threaded (NPT) end connections for direct installation into standard pipe runs
• Brass construction provides corrosion resistance in water and general-purpose plumbing service
• Compact single-body design eliminates the need for additional tee fittings and multiple valves
• Order increment of 1 — sold individually

Compatibility

Designed as an OEM-style replacement or new-installation valve for standard 1-1/2 inches NPT threaded pipe systems in residential and commercial plumbing and hydronic applications.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the IPC. Shut off the water supply and relieve system pressure completely before removing any existing valve or fitting. Use appropriate thread sealant or PTFE tape on all NPT connections and avoid over-tightening, which can crack brass fittings. Confirm valve handle orientation matches intended flow path before returning the system to service.

Technical Specifications

• Connection Size: 1-1/2 inches
• Connection Type: Threaded (NPT)
• Valve Configuration: 3-Way Ball Valve
• Material: Brass
• Weight: 5.22 pounds
• UPC: 670750674037

Standard Information

• Brand: WESTLAKE PIPE FITTINGS
• Manufacturer Part Number: 7060701
